Product Features
23" DECK HEIGHT — HAUL WHAT OTHERS CAN'T
The double drop well puts your cargo at just 23" off the ground — critical for over-height loads that would require permits on a standard step deck. Built for excavators, cranes, industrial machinery, and more.
BUILT TO YOUR LOAD
The Double Drop isn't a one-size trailer — well length, axle count (tandem, triple, quad), and GVWR from 60K to 100K+ are all specced to your exact hauling needs. Call out that Behnke builds it to order.
1-PIECE I-BEAM STRENGTH
The entire frame — neck, drops, and well — is built from 1-piece manufactured I-beam with 80K web and T1 flanges. 6" Jr. I-beam crossmembers throughout the well section keep the deck rigid under load.
TANDEM, TRIPLE, OR QUAD
25,000 lb air brake axles with Hutch H9700 or Ridewell RAR240 suspension. Configure 2, 3, or 4 axles to match your payload and road weight requirements. Air ride suspension upgrade available for sensitive cargo.
DECK THAT WORKS AS HARD AS YOU DO
1-1/2" rough oak decking in both the upper and well sections, paired with 1" bent d-rings throughout. Optional chain slots or outriggers available for non-standard loads.
POWDER COATED FOR THE LONG GAME
Bead blasted, acid washed, zinc-rich primed, then powder coated. Call out the beavertail option and the taper-from-well-to-axles option — small details that make a big difference loading wheeled equipment.
Product Details
DIMENSIONS
- LENGTH:
- 10' wood upper + specify well length
- WIDTH:
- 102"
- UNLOADED DECK HEIGHT:
- 23"
- TRAILER TYPE:
- Double Drop / Lowboy
- PULL TYPE:
- King Pin (Semi Trailer)
- COLLECTION:
- Heavy Haul — Semi-Style
WEIGHT RATINGS
- GVWR:
- 60,000 - 100,000 lbs
- GAWR:
- 25,000 lbs (per axle)
- ESTIMATE DRY WEIGHT:
- Various
- AXLE COUNT:
- 2, 3, or 4 (tandem/triple/quad)
FINISH
- PAINT TYPE:
- Powder Coated
- PREP:
- Bead Blasted, Acid Washed, Zinc Rich Primed
- UNDERCOAT:
- Zinc Rich Primer
KING PIN
- TYPE:
- 2" King Pin
- LANDING GEAR:
- (2) Dual Speed Semi-Style Landing Gears
FRAME & CONSTRUCTION
- FRAME:
- 1-Piece Fabricated I-Beam (80 KSI)
- CROSSMEMBERS:
- 6" Jr. I-Beams (80 KSI)
- FLOORING:
- 1-1/2" Rough Oak
- SIDE RAILS:
- Fabricated I-Beam
- FENDERS:
- 1/4" Sheet
RUNNING GEAR
- AXLE TYPE:
- 25,000 lb Air Brake Axles
- SUSPENSION:
- Hutch H9700 or Ridewell RAR240
TIRES & WHEELS
- TIRE TYPE:
- Dual
- TIRE SIZE:
- 255/70R-22.5
ELECTRICAL & LIGHTING
- 7-WAY RECEPTACLE:
- Semi Plug
- LIGHTING:
- LED Flush Mount
CARGO & TIE-DOWN
- D-RINGS:
- 1" Bent D-Rings
OPTIONS
